CF-BP1201
26" Steel Bicycle Frame with Fork
TIG-welded high-carbon steel frame for city and mountain builds, available with rigid or suspension fork.
- Model No.CF-BP1201
- Size Range24" / 26" / 27.5" / 700C
- MaterialHigh-carbon steel, TIG welded
- Frame19–21 inch frame height
- ForkRigid or 60 mm suspension
- BrakeV-brake mounts, disc mounts optional
Send us your quantity and destination port — we will reply with our best FOB price and packing details.
Description
We supply frames as the backbone of overseas assembly operations. Tubes are TIG-welded, then aligned on a granite table to a tolerance of ±1 mm at the dropouts, and finally powder coated. Available in rigid and suspension-fork versions, with or without disc-brake mounts, and with your own decals. Each frame is individually wrapped with foam at the dropouts and packed in a 5-layer export carton rated for sea freight stacking.
Key Features
- TIG-welded, dropout alignment within ±1 mm
- Rigid or suspension fork option
- Disc-brake mounts optional
- Foam-wrapped dropouts, 5-layer export carton
Specifications
| Model No. | CF-BP1201 |
|---|---|
| Size Range | 24" / 26" / 27.5" / 700C |
| Material | High-carbon steel, TIG welded |
| Frame | 19–21 inch frame height |
| Fork | Rigid or 60 mm suspension |
| Brake | V-brake mounts, disc mounts optional |
| Colour Options | Any RAL / Pantone, powder coated |
| Net Weight | 3.6 kg per frame |
| Certification | EN14764 / ISO 9001 |
| Packing | 5 pcs / carton, foam wrapped |
| MOQ | 500 pcs |
| Loading Port | Tianjin |
| Lead Time | 25–30 days after deposit |
